24V 1000A/48V 500A/80V 300A/120V 200A 30kw High Frequency Industrial Forklift Battery Charger
The 30kw high frequency industrial forklift battery charger is designed for battery charging and is suitable for a variety of battery cycle charging.
- Category: Charger
- Tag: Forklift Battery Charger
24V 1000A/48V 500A/80V 300A/120V 200A 30kw High Frequency Industrial Forklift Battery Charger
An intelligent high-frequency charger is designed for battery charging, the use of high-frequency switching power supply technology, modular installation structure design, the whole system by PFC unit, power conversion unit, monitoring unit, display unit, electrical unit, communication protection unit, charging connection part, the charging process is automatic, to achieve all kinds of battery intelligent charging management. Suitable for all kinds of battery cycle work charging, generally used in ordinary forklift charging piles, electric bicycle charging piles, shared charging piles, scanning charging piles, electric vehicle scanning charging, robot charging, new energy vehicle charging, etc.
Specifications
Model | EVL6133 | EVL6134 | EVL6122 | EVL6143 |
DC Voltage | 24V | 48V | 80V | 120V |
Rated Current | 1000A | 500A | 300A | 200A |
Current Range | 1-1000A | 1-500A | 1-300A | 1-200A |
Range of Output Voltage | 18-30V | 38-60V | 65-100V | 92-132V |
Input Voltage | 220V±10%/ 380V±10% | 220V±10%/ 380V±10% | 220V±10%/ 380V±10% | 220V±10%/ 380V±10% |
Input Current | 30A | |||
Output Power | 30KW | |||
Input Mode | L1+L2+L3+PE three-phase four-wire system/ L1+L2+L3+N+PE three-phase five-wire system | |||
Power Factor | >0.99 | |||
THD | <10% | |||
Efficiency | >95 | |||
Current Ripple | ±3% | |||
Current Precision | ±0.5% | |||
Voltage Precision | ±0.5% | |||
Ripple Voltage | ≤±1%Vo peak-to-peak value,20Mhz bandwidth, | |||
Charging Precision | Voltage/0.01V Current/0.1A Time/1S | |||
BMS Power Supply | 12V/24V Optional | |||
Protection Function | OTP、OVP、OCP、Short | |||
Connector | Anderson/International charging gun/ REMA/The customer agreement | |||
Communication Method | RS485、RS232、CAN Bus | |||
MTBF | 80000H | |||
Safety | CE、UL1564,IEC61851 | |||
Display | LCD/LED | |||
Cooling | Air Fan | |||
Working/Storage temperature and humidity | Working: -20℃ to 65℃ Storage:-40℃ to 85℃ | |||
Applications
Generally used in ordinary forklift charging piles, electric bicycle charging piles, shared charging piles, scanning charging piles, electric vehicle scanning charging, robot charging, new energy vehicle charging, etc.
