SE-G5.3 51.2V 103Ah 5.32Kwh LiFePO4 Server Rack Battery For ESS
SE-G5.3 51.2V 103Ah 5.32Kwh lifepo4 server rack battery for ess, application high power, limited installation space, restricted load bearing, and long cycle life.
- Category: Energy storage system
- Tag: 51.2V 103Ah 5.32Kwh server rack battery for ess
Specifications
Main Parameter | ||
Battery Chemistry | LiFePO4 | |
Capacity (Ah) | 104 | |
Scalability | Max. 64 pcs pack (340kWh) in parallel (Max. 32 pcs no external setup) | |
Nominal Voltage (V) | 51.2 | |
Operating Voltage(V) | 43.2~57.6 | |
Energy (kWh) | 5.32 | |
Usable Energy (kWh) [1] | 4.79 | |
Charge/Discharge Current (A) | Recommend [2] | 50 |
Max.[2] | 100 | |
Peak | 120(30s,25) | |
Other Parameter | ||
Recommend Depth of Discharge | 90% | |
Dimension (W/H/D, mm) | 440*133*560 | |
Weight Approximate(kg) | 45 | |
Master LED Indicator | 5LED(SOC:20%~SOC100%), 3LED (working, alarming, protecting) | |
IP Rating of Enclosure | IP20 | |
Operating Temperature | Charge: 0～55℃(Optional heating) / Discharge: -20℃～55℃ | |
Storage Temperature | 0℃～35℃ | |
Humidity | 5%~95% | |
Altitude | ≤2000m | |
Cycle Life | ≥6000(25℃±2℃,0.3C/0.3C, 90% DOD, 70% EOL) | |
Installation | 19-inch standard rack (depth ≥600mm / with), Floor-Mounted, Wall-Mounted, | |
Communication Port | CAN2.0, RS485 | |
Warranty Period [3] | 5 years | |
Energy Throughput [3] | 16MWh@70%EOL | |
Certification | CE, IEC62619, UN38.3 | |
This series is especially suitable for application scenes of high power, limited installation space, restricted load bearing, and long cycle life.
This series battery has a built-in BMS B attery M anagement S system which can manage and monitor cells information including voltage, current, and temperature. What’s more, BMS can balance cell charging to extend cycle life.
Multiple batteries can connect in parallel for larger capacity and longer power-supporting duration requirements.
Features
Safer
Cobalt Free Lithium Iron Phosphate (LFP) Battery: Safety and long Lifespan, high efficiency, and high power density.
Intelligent BMS, providing complete protection.
Reliable
Support high discharge power. IP20, natural cooling, wide temperature range: -20℃ to 55℃.
Flexible
Modular design, easy to expand, Max. 64 units in parallel, Max. capacity of 340kWh.
Suited to residential and commercial applications for increasing the self-consumption ratio.
Convenient
Battery module auto networking, easy maintenance, support remote monitoring and upgrade, support USB drive upgrade the firmware.
Eco-Friendly
Use environmental protection materials, the whole module is non-toxic, and pollution-free.
