EF651625 3.6 v 750mAh Li-SOCl2 Non Rechargeable Lithium Battery
EF651625 3.6v 750mAh Li-SOCl2 Non-Rechargeable Lithium Battery Smart Meter Counts IoT Devices
- Category: Lithium Thionyl Chloride Li SOCl2 Battery
- Tag: Li SOCl2 battery
F651625 lithium-ion battery is a high-quality lithium battery with high energy, high performance, high safety and strong adaptability. It has a continuous and stable voltage to provide a stable power supply for your small equipment.
Feature
· Voltage stabilization
· High energy density
· Low self-discharge rate
· No memory effect
· Fully sealed construction
· Wide temperature range
Specification
Parameter | Specification |
Model | EF651625 |
Nominal voltage | 3.6V |
Nominal capacity | 750mAH |
Maximum continuous discharge current | 10mA |
Maximum pulse discharge current | 30mA |
Lithium Weight | 8g |
Self-discharge rate | ≤1% |
Natural storage life | 10 years |
Storage temperature | - 20℃~ + 25℃ |
Operating temperature | -55℃~ + 85℃ |
Dimension | 16.85x25.8x7.0(mm) |
Product Details
3.6V Li SOC2 Battery Series
Model | Nominal voltage （V） | Nominal capacity (mAh) | Maximum continuous current(mA)
| Maximum pulse current(mA) | Weight (g) | Operating temperature(℃) | Dimension(mm) |
3.6 | 1200 | 35 | 50 | 10 | -55~+85℃ | 14.5x25.4 | |
3.6 | 1650 | 35 | 75 | 12 | -55~+85℃ | 14.5x33.5 | |
3.6 | 2700 | 60 | 150 | 19 | -55~+85℃ | 14.5x50.5 | |
3.6 | 3600 | 100 | 180 | 26 | -55~+85℃ | 17.5x51.0 | |
3.6 | 4000 | 130 | 180 | 28 | -55~+85℃ | 18.7x50.5 | |
3.6 | 8500 | 150 | 200 | 52 | -55~+85℃ | 26.2x50.0 | |
3.6 | 19000 | 230 | 300 | 100 | -55~+85℃ | 33.1x61.5 | |
3.6 | 400 | 5 | 20 | 5 | -55~+85℃ | 16.85x15.8x7.0 | |
3.6 | 750 | 10 | 30 | 8 | -55~+85℃ | 16.85x25.8x7.0 | |
3.6 | 1600 | 20 | 50 | 16 | -55~+85℃ | 23.3x38.3x7.5 | |
3.6 | 550 | 5 | 20 | 9 | -55~+125℃ | 24.3x6.2 | |
ER32L65 | 3.6 | 1000 | 10 | 50 | 19 | -55~+85℃ | 32.9x7.1 |
3.6 | 1700 | 10 | 50 | 24 | -60~+85℃ | 32.9x10 |
Product Certifications
Application aspect
Suitable for small devices: 750mAh capacity and small size, especially suitable for smart wearable devices, mini medical monitoring instruments, small security sensors, Internet of Things terminal equipment and other space and power requirements of small electronic devices.
