51.2V 280Ah/314Ah 1P16S Air Cooling LiFePO4 Battery Pack

Feature

· Voltage and capacity adaptation: Rated voltage 51.2V, rated capacity 280Ah, can meet the power supply requirements of a variety of medium power equipment.

· Sufficient energy: nominal energy 14.3kWh, continuous and stable power supply.

· Wide operating voltage range: the voltage range is 40-58.4V, suitable for different working conditions.

· Charge and discharge ratio is moderate: the charge and discharge ratio is 0.5C, which can meet the demand of charge and discharge speed in conventional use scenarios.

· Good heat dissipation: The air-cooled heat dissipation system effectively controls the battery temperature and improves the battery cycle life and stability.

· Reasonable size design: 760mm×480mm×236mm, easy to install and integrate into different equipment or systems.

Specifications

Test and certification

Applications

Energy storage system: can be used for power grid energy storage, distributed generation energy storage and other fields, storage of excess energy, play a role in regulating power supply and demand, stable grid voltage and frequency.

Light electric vehicles: provide power support for electric motorcycles, electric tricycles, etc., and its voltage and capacity can meet the driving needs of such vehicles.

Small mobile power supply: As a small mobile power supply, it provides temporary power guarantee for outdoor operation equipment, emergency rescue equipment, etc.

Solar and wind power: Used in conjunction with solar panels or wind turbines to store the electricity generated by the power generation system so that it can supply power when needed.
