Upgrade your scrubber with our powerful and long-lasting LifePO4 24V 100Ah Battery Pack. Experience unmatched performance, enhanced efficiency, and reliability. Say goodbye to downtime and hello to pr
Unmatched Power and Efficiency:
Experience a new level of power and efficiency with our LifePO4 24V 100Ah Battery Pack. Engineered with the latest lithium iron phosphate (LiFePO4) technology, it delivers a consistent and high voltage output, ensuring optimal performance of your scrubber. This means longer runtimes, faster charging cycles, and improved overall efficiency, allowing you to cover more area in less time.
Long-lasting Performance:
Tired of constantly replacing batteries? Our LifePO4 24V 100Ah Battery Pack is built to last. With its exceptional cycle life and deep discharge capabilities, it outperforms traditional lead-acid batteries by a significant margin. Enjoy extended battery life, reduced maintenance costs, and peace of mind knowing that your scrubber will keep going strong, even in demanding cleaning environments.
Enhanced Safety and Reliability:
Safety is a top priority, and our battery pack is designed with multiple layers of protection. Equipped with advanced battery management systems (BMS), it offers comprehensive safeguards against overcharging, over-discharging, overheating, and short circuits. You can trust in the reliability of our battery pack to provide a safe and worry-free cleaning operation.
Easy Integration and Versatility:
Our LifePO4 24V 100Ah Battery Pack is designed for seamless integration with a wide range of scrubber models. Whether you have a walk-behind scrubber, ride-on scrubber, or any other type, our battery pack is compatible and ready to power your machine. Its compact size and lightweight design make installation hassle-free, allowing you to get back to cleaning in no time.
Environmentally Friendly Solution:
Reduce your carbon footprint and contribute to a greener future with our eco-friendly battery pack. Unlike traditional lead-acid batteries, our LifePO4 technology is free from harmful heavy metals, making it a more sustainable and environmentally responsible choice. Make a positive impact on both your cleaning operations and the planet.
Items | Parameters | ||
Nominal voltage | 24V | ||
Nominal capacity | 100Ah | ||
Rated voltage | 25.6V | ||
Max. continuous charge current | 30A (0.3C) | ||
Max. continuous discharge current | 60A(0.6C) | ||
Max. pulse discharge current | 100A(1C, 15S) | ||
Cycle life | 2000 cycles, 80%DOD | ||
Charge limited voltage | (29.2±0.05) V | ||
Discharge cut-off voltage | 20V | ||
Charging time | 3h (0.3C) | ||
Charge discharge efficiency | ≥95% | ||
Cooling way | nature | ||
IP Grade | IP65 | ||
Operating temperature range | Charge | (0-60)℃ | |
Discharge | (-20-60)℃ | ||
RH Relative humidity | (65±20) % | ||
Combination | 8S18P | ||
Weight | ≤28Kg |
Charging
The battery charging temperature range is (0-60)°C.
Use a lithium-ion battery charger with constant current and constant voltage.
Ensure correct polarity when connecting the battery, and strictly avoid reverse charging. Reversing the polarity may result in electric arcs and short circuits.
During charging, the discharge port remains energized due to the MOSFET switching control of the protection board. To prevent electric shock or short circuits, avoid contact or vehicle movement while charging.
Discharging
The battery discharging temperature range is (-20-60)°C.
During prolonged periods of non-use, the battery may experience over-discharge due to self-discharge characteristics. To prevent over-discharge, it is recommended to periodically charge the battery and maintain individual cell voltages between (3.3-3.5) V. Over-discharge can lead to a loss of battery performance and functionality.
When discharging, the charging port remains energized due to the MOSFET switching control of the protection board. Avoid touching the port to prevent electric shock or short circuits.
