4LH3L 3.2V 315Ah Prismatic LiFePO4 Cell

battery 4LH3L 3.2V 315Ah Prismatic LiFePO4 Cell for energy storage system

4LH3L 3.2V 315Ah Prismatic LiFePO4 Cell4LH3L 3.2V 315Ah Prismatic LiFePO4 Cell


Specifications

ITEM

SPECIFICATION

Nominal Capacity

315.0Ah

Nominal voltage

3.2V

Charge voltage (End current)

3.65V

Discharge ending voltage

2.5V

Nominal energy

1008Wh@0.5C

Max continuous discharge current

315A

Max. peak discharge current

630A@30S

Max. continuous charge current

157.5A

Charge temperature range

0~6 0℃

Discharge temperature range

-30~60℃

Storage temperature

-30~60℃

Internal resistance

≤ 0.3 mΩ (AC Impedance, 1000 Hz)

Cycle life

≥5000cycles (standard charge/discharge)

Recommended SOC Window

SOC: 0%~100%

Cell size

71.65(T)*173.93(W)*207.23(H)±0.6mm

Weight

5.550±0.150kg



4LH3L 3.2V 315Ah Prismatic LiFePO4 Cell4LH3L 3.2V 315Ah Prismatic LiFePO4 Cell
