32140 2.3V 9Ah Lithium Titanate Lto Battery Cell
9Ah 2.3V 32140 Lto Lithium Titanate Battery with 10C high charge/discharge rate and super long cycle life
- Category: Lithium Titanate LTO Battery
- Tag: Lithium Titanate LTO Battery
32140 2.3V 9Ah Lithium Titanate Lto Battery Cell
The lithium titanate battery (Li4Ti5O12）is a type of rechargeable battery based on advanced nano-technology, which has a super long cyclelife of more than 25000times, a fast charge/discharge rate (up to 10C) and wide working temperature range(-50°C ~ 65°C).
FEATURES & PERFORMANCE SAFETY PROTECTION
• 20000 LIFE CYCLES • OVERCHARGING
• INCREASED SAFETY PERFORMANCE • OVER-DISCHARGING
• WIDE OPERATING TEMPERATURE RANGE • SHORT CIRCUIT
• HIGH-TEMPERATURE PERFORMANCE • PENETRATION
• GREEN ENERGYWITHOUT CONTAMINANTS • THERMAL SHOCK
• PRESSURE-RESISTANT CELLS • NO FIRES
• HIGH CAPACITY SYSTEM • NO EXPLOSIONS
• STEADY OUTPUT VOLTAGE
• <3% YEARLY DISCHARGE STORAGE
• TRIPLE SAFETY PROTECTION
• VIBRATION & SHOCK-RESISTANT
• NO MEMORY EFFECT
Details
No | Item | Parameters |
1 | Rated Capacity | 9Ah |
2 | Nominal Voltage | 2.3V |
3 | Internal Impedance | ≤1.5mΩ |
4 | Standard Charge Cut-off Voltage | 2.8V |
5 | Standard Discharge Cut-off Voltage | 1.5V |
6 | Maximum Continuous Charge Current | 10C(90A) |
7 | Maximum Continuous Discharge Current | 10C(90A) |
8 | Maximum Pulse Charge/Discharge Current(10s) | 20C(180A) |
9 | Operating Temperature Range | Temperature:-40~65℃ Humidity: ≤85%RH |
10 | Storage Temperature Range | -5℃~28℃ |
11 | Dimension | 33*140mm |
12 | Weight | 270±13g |
13 | Cycle Life | The cell shall be continuously charged and discharged for 16000 cycles. |
