Lithium Solar Batteries 48V 100Ah LiFePO4 5KWh Backup Household Batteries
48V 100Ah LiFePO4 backup batteries offer longer life, lighter weight, higher power, superior safety, and wide temperature range for reliable, cost-effective performance.
Features of 48V 100Ah LiFePO4 Backup Batteries:
● Longer Cycle Life: Offers up to 10 times longer cycle life and 5 times longer float/calendar life than lead acid battery. Helping to minimize replacement cost and reduce total cost of ownership.
● Lighter Weight: About 40% of the weight of a comparable lead acid battery. A ”drop in” replacement for lead acid battery.
● Higher Power: Delivers twice power of lead acid battery, even high discharge rate, while maintain high energy capacity.
● Wider Temperature Range: -10℃~60℃
● Superior Safety: Lithium iron phosphate chemistry eliminates the risk of explosion or combustion due to high impact, over charging or short circuit situation.
● No Memory Effect: Support unstable partial state of charge (UPSOC) (charge/discharge) utilization.
Specifications of 48V 100Ah LiFePO4 Backup Batteries:
Item | Parameter |
Rated Voltage | 48V |
Rated Capacity | 50AH |
Working Voltage Range | 42-54.6V |
Charge Current (Recommended) | 10A |
Continuous Discharge Current | 50A |
Life Cycle Time（80%DOD） | 5000 times |
Calendar Life | 10years |
Size | 480mm*477mm*177mm |
Weight | ~32kg |
Charge Temperature | 0~55℃ |
Discharge Temperature | -20~55℃ |
Status Indicators | SOC/ALM/RUN |
Communication Ports | 1*RS232/2*RS485/2*CAN |
Reset Key | Available |
LCD Screen | Optional |
Communication in Parallel | 15 models in maximum |
Functions of BMS:
Over-charge detection function
Over-discharge detection function
Over-current detection function
Temperature protection function
Short circuit detection function
Balance function
